As with electric fuel level meters, SHAOXING HUAZHEN’s temperature meter is designed with a silicone dampened air core movement, 90° sweep, and have the same case withstanding adverse environments. These gauges require a sender which must match the gauge type, see Temperature Sensor.

  • Standard 2" (52mm) or 2-3/8” (60mm) galvanized white iron case with single U-shaped bracket mounting
  • Scratch resistant glass lens and rubber bush are filled onto iron case to resist corrosion and vibration
  • Optional LED or bulb backlit illumination, red yellow or white pointer with black hub, bright chrome or black bezel are available
  • Wiring leads are totally sealed by rubber stopple
  • Easy to read graphics can be customized
  • Precision: ±3% full scale @ -7℃～54℃
  • Nominal voltage: 12V (DC9V～16V) or 24V (18V～32V)

P/N:  HZ25111-BR    12V Temperature meter
P/N:  HZ25121-BR    24V Temperature meter

  • Standard 2"(52mm) metal housing
  • Single U-shape bracket mounting
  • LED backlit illumination
  • Pointer sweeps 90 degree
  • Precision ±3% full scale
  • Warranty: One year

P/N:  HZ25111-WR    12V Temperature meter
P/N:  HZ25121-WR    24V Temperature meter

  • Standard 2"(52mm) metal housing
  • Single U-shape bracket mounting
  • LED backlit illumination
  • Pointer sweeps 90 degree
  • Precision ±3% full scale
  • Warranty: One year

P/N:  HZ25112-BR    12V Temperature meter
P/N:  HZ25122-BR    24V Temperature meter

  • Standard 2"(52mm) metal housing
  • Single U-shape bracket mounting
  • LED backlit illumination
  • Pointer sweeps 90 degree
  • Precision ±3% full scale
  • Warranty: One year

P/N:  HZ25112-WR    12V Temperature meter
P/N:  HZ25122-WR    24V Temperature meter

  • Standard 2"(52mm) metal housing
  • Single U-shape bracket mounting
  • LED backlit illumination
  • Pointer sweeps 90 degree
  • Precision ±3% full scale
  • Warranty: One year

P/N:  HZ25312-WR    12V Temperature meter

P/N:  HZ25322-WR    24V Temperature meter

  • Standard 2"(52mm) metal housing
  • Single U-shape bracket mounting
  • LED backlit illumination
  • Pointer sweeps 90 degree
  • Precision ±3% full scale
  • Warranty: One year

P/N:  HZ25412-BR    12V Temperature meter
P/N:  HZ25422-BR    24V Temperature meter

  • Standard 2"(52mm) metal housing
  • Single U-shape bracket mounting
  • LED backlit illumination
  • Pointer sweeps 90 degree
  • Precision ±3% full scale
  • Warranty: One year

P/N:  HZ25412-WR    12V Temperature meter
P/N:  HZ25422-WR    24V Temperature meter

  • Standard 2"(52mm) metal housing
  • Single U-shape bracket mounting
  • LED backlit illumination
  • Pointer sweeps 90 degree
  • Precision ±3% full scale
  • Warranty: One year

P/N:  HZ25612-BR    12V Temperature meter
P/N:  HZ25622-BR    24V Temperature meter

  • Standard 2"(52mm) metal housing
  • Single U-shape bracket mounting
  • Bulb flooding light illumination
  • Pointer sweeps 90 degree
  • Precision ±3% full scale
  • Warranty: One year

P/N:  HZ25712-BR    12V Temperature meter
P/N:  HZ25722-BR    24V Temperature meter

  • Standard 2"(52mm) metal housing
  • Single U-shape bracket mounting
  • LED backlit illumination
  • Pointer sweeps 90 degree
  • Precision ±3% full scale
  • Warranty: One year

P/N:  HZ25812-BR    12V Temperature meter
P/N:  HZ25822-BR    24V Temperature meter

  • Standard 2"(52mm) metal housing
  • Single U-shape bracket mounting
  • LED backlit illumination
  • Pointer sweeps 90 degree
  • Precision ±3% full scale
  • Warranty: One year

P/N:  HZ25912-BR    12V Temperature meter
P/N:  HZ25922-BR    24V Temperature meter

  • Standard 2"(52mm) metal housing
  • Single U-shape bracket mounting
  • LED backlit illumination
  • Pointer sweeps 90 degree
  • Precision ±3% full scale
  • Warranty: One year
