Vertical Battery Indicator
Memory Type - 4 terminals
HT0624V Series
Panel cutout: Rectangular 37x25mm
High Reliability & durability
Features：
Battery discharge indicator
10 tri-color LED bar shows the real battery state.
Terminals: Max. 4; 3/16"-spades
Mounting: Surface mount with 2 screws in vertical
Lens Material: Poly glass
Case Material: ABS (Black)
Panel Cutout (mm): rectangular 37x25mm
Operating Temperature: -40℃ to +85℃
Storage Temperature: -50℃ to +90℃
Humidity: 95% RH (Non Condensing) at 38℃
Operating voltage: ±25% of rating voltage; 12/24V; 12V; 24V; 36V; 48V
EEPROM memory
How to order：
Please note in different applications the discharge curve of the battery sets might be different. The detecting range of HT0624H series can't be recalibrated by users when leaving factory.
Please consult to our professional sales sales@sxhzelect.com on customized detecting range.
Part Number & Description:
| Part Number | Volts | Terminal | Functions |
| HT0624V-12/24 | 12/24V | +,- | |
| HT0624V-36 | 36V | +,- | |
| HT0624V-48 | 48V | +,- | |
| HT0624VC-12/24 | 12/24V | +,-,C | LED enable |
| HT0624VC-36 | 36V | +,-,C | LED enable |
| HT0624VC-48 | 48V | +,-,C | LED enable |
| HT0624VR-12/24 | 12/24V | +,-,R | Relay lockout |
| HT0624VR-36 | 36V | +,-,R | Relay lockout |
| HT0624VR-48 | 48V | +,-,R | Relay lockout |
| HT0624VRC-12/24 | 12/24V | +,-,R,C | LED enable & Relay lockout |
| HT0624VRC-36 | 36V | +,-,R,C | LED enable & Relay lockout |
| HT0624VRC-48 | 48V | +,-,R,C | LED enable & Relay lockout |
For customized features please contact Ms. Rebecca Chen: sales@sxhzelect.com
